FM Pallet (A Series)

FM Pallet 1500 watt


FM Pallet 1500 watts



Product Code: A1500-FM

  Price $1,427.00


The A1500-FM designed for FM radio transmitter. This Amplifier incorporates micro strip technology and MOSFET transistor to enhance ruggedness reliability.


This is the new generation of low cost, high gain and high efficiency FM pallets amplifiers for professional use with outstanding performances.


iWin is proud to announce the launch a new generation of FM pallets using the NXP power device. This amplifier uses a double BLF178P transistor to produce up to 1500watts. This module using standard Wilkinson splitter and combiners. Please provide the best impedance match for this pallet to prevent power losses.


Note: This product is provided for experienced FM transmitter fabricators only. If you are not experienced please buy a complete FM amplifier module.



Product Feature:


  • 87.5-108MHz
  • Input/output impedance 50 ohm
  • Gain: 25 dB
  • 40 Volts
  • Pout: 1500W
  • Devices : BLF178P X 2




Technical Specifications:



Power output

1500 watts

Input/output impedance

50 Ohm

Gain

25 dB (typical)

Power input

8 watt type

Frequency range

87.5 MHz รท 108 MHz

Efficiency

80% type (@1500watts)

Power requirement

45A@40V (typical 1500W)

Panel size

320 x 105 x 35 mm (L x W x H)

Shipping weight

1.6 kg




Document Download:



Datasheet A1500-FM.PDF
